MTL 8507-BI-DP|Signal isolation controller |

$9,549.00

In stock

Manufacturer:8507-BI-DP

  • PC with MTL838C Configuration Software installed.
    Power Supply: 24V @ 200mA
    Cabling for the following connections:
    Data highway connections (refer to INM831C and INM838C manuals)
    Power supply connections
    USB cable

AAll products on this website are discounted products, and market prices have been fluctuating. Please refer to customer service quotes for details. Pictures are not actual photos. Before placing an order, please confirm the model, product, price, and other detailed information with customer service. Both second-hand and brand new products are available for sale on this website. Please contact customer service for further communication.



  • PC with MTL838C Configuration Software installed.
    Power Supply: 24V @ 200mA
    Cabling for the following connections:
    Data highway connections (refer to INM831C and INM838C manuals)
    Power supply connections
    USB cable

MTL 8507-BI-DP|Signal isolation controller |

MTL 8507-BI-DP|Signal isolation controller |illustration

Connect the Power Supply:



Ensure your power supply provides 24V at 200mA.

Connect the power supply to the MTL831C and MTL838C units as specified in the manuals.

Establish Data Highway Connections:



Refer to the INM831C and INM838C installation manuals for detailed wiring instructions.

Ensure the data highway connections between the MTL831C and MTL838C are properly set up.

Connect the USB Cable:



Connect the MTL838C receiver to the PC using a USB cable.

Sensor Connection:



Connect at least one sensor to the MTL831C transmitter.

Testing the System

Power Up: Once all connections are made, power up the system.

Configure the System: Use the MTL838C Configuration Software on your PC to configure the MTL838C receiver.

Verify Communication: Check the communication between the MTL831C transmitter and MTL838C receiver via the software.

Test Sensor Readings: Ensure the sensor connected to the MTL831C is providing accurate readings as displayed in the configuration software.

Summary

Following these steps, you should be able to set up a simple test system to familiarize yourself with the MTL830C system. Detailed wiring and configuration instructions can be found in the respective installation manuals (INM831C and INM838C).
