The processor modules of the ME203 series extend the range of the M1 controller family in terms of reduced power consumption and moderate cycle times. With an extremely slim design of only one module width, ME203 CPUs offer all the essential features of larger type series but with a lower power consumption. Several networking and power supply options scale the module ideally for smaller applications. As fully-fledged M1 CPUs, ME203 processor modules are not only configured with the same tools as the high-end families MX and MPC, but are also fully code and application compatible, although they have less memory and fewer interfaces. All modules have two serial interfaces and a front slot for one PC card.
The optional Ethernet interface allows integration in 10 / 100 Mbit / s networks at full data rate. With the retentive program and data storage devices, also larger projects can be handled without the need for external media. In addition to the supply of the processor module, an integrated optional power supply provides 17 W for extra I/O modules.
• 80386 EX processor
• 2 serial interfaces
• Optional integrated power supply, 17 W / 24 V DC
• Optional CAN bus interface
or Ethernet 100 Mbit 100 Mbit / s interface
• RAM 8 MB DRAM
• Data memory 512 kB SRAM, (battery backed)
• Integrated program memory
• Removable memory:
PC cards with 8 / 16 / 32 / 64 MB
• Battery backed real-time clock (RTC)
• Status displays for RUN, INIT and ERROR
• Watchdog
