The SCE9x3/4/5 are capable of direct line operation. All units are fully isolated and do not require external isolation transformers. Also, the inrush current on connection to the line is internally limited to a safe level for the drive. There are no voltage selection or ranging switches required to operate within the specified voltage input ranges. It is the responsibility of the user to supply appropriate fuses or circuit breakers in the J1 AC Power motor power lines to comply with local electrical codes.
The control input power required depends on the option card plugged in and the load on user +5 VDC. It should be between 15 and 30 watts. The AC input motor power depends on output power and the losses in the power stage. The control power input has a single fuse in line with one of the AC line inputs.
480 VAC Three Phase Input 650 VDC
400 VAC Three Phase Input 540 VDC
240 VAC Three Phase Input 320 VDC
As the user or person applying this unit, you are responsible for determining the suitability of this product for the application. In no event will Danaher Motion Pacific Scientific be responsible or liable for indirect or consequential damage resulting from the misuse of this product. Read this manual completely to effectively and safely operate the SCE900 series unit.
OCE900-001 Blank panel to cover option slot
OCE930-001-00 Serial communications option card RS-232 or RS-485 to set parameters
OCE940-001-01 SERCOS interface option card industry standard LAN fiber optic interface for command and to set parameters
OCE950-50x-01 Standard single-axis programmable positioning option card
OCE950-60x-01 Enhanced single-axis programmable positioning option card
