SB171 3BSE004802R1 ABB Standby power supply unit

There is no configuration required to the physical Input Module. All
configurable characteristics of the Module are performed using tools on the
Engineering Workstation (EWS) and become part of the application or
System.INI file that is loaded into the TMR Processor. The TMR Processor
automatically configures the Input Module after applications are downloaded
and during Active/Standby changeover.
The IEC 61131 TOOLSET provides the main interface to configure the Input
Module. Details of the configuration tools and configuration sequence are
provided in Trusted Toolset Suite Product Description, publication ICSTTRM249 (PD-T8082). There are three procedures necessary to configure the
Input Module. These are:
1. Define the necessary I/O variables for the field input data and module
status data using the Dictionary Editor of the IEC 61131 TOOLSET.
2. Create an I/O Module definition in the I/O Connection Editor for each
I/O Module. The I/O Module definition defines physical information,
e.g. Chassis and Slot location, and allows variables to be connected to
the I/O channels of the Module.
3. Using the Trusted® System Configuration Manager, define custom
LED indicator modes, per-channel threshold levels and noise filtering,
and other Module settings.

The ‘Primary Module is active’ channel is set to nonzero if the primary Module
is the current Active Module, i.e. the Active Module is in the chassis and slot
numbers defined within the OEM parameters.
The ‘Active Module is simulated’ channel is set to ‘1’ if the Active Module is
being simulated, this will only be set if the module is not present or nonoperational and the simulation enable has been set within the Module’s
configuration in the System.INI file.
Each Boolean Input Variable can be configured for automatic Sequence of
Events (SOE) logging. This applies to the Input Status and Line Fault Status
variables. A Boolean variable is configured for SOE during the variable
definition in the Data Dictionary Editor. To select SOE, press the Extended
Button in the Boolean Variable Definition Dialog Box to open the Extended
Definition Dialog. Then check the box for Sequence of Events to enable the
variable for automatic SOE logging.
During operation, the Input Module automatically reports time-stamped
change of state information for the input data. The TMR Processor
automatically logs change of state for configured SOE variables into the
system SOE Log. The SOE Log can be monitored and retrieved using the SOE
and Process Historian Package running on the EWS. This software package is
described in Trusted Sequence of Events and Process Historian Package
Product Description, publication ICSTT-RM243 (PD-T8013).
