ABB YPQ110A 3ASD573001A5 Analog Expansion Module

ABB YPQ110A 3ASD573001A5 Analog Expansion Module

Contents of this chapter

In this chapter, the drive module and LCL filter module are installed in a 800 mm wide Rittal VX25 enclosure in a bookshelf way. The modules are placed in an upright position on the enclosure bottom with the front facing the enclosure door. Space for the additional components can be made by connecting two or more VX25 enclosures together. Available alternative ABB parts are also given.

Limitation of liability

The installation must always be designed and made according to applicable local laws and regulations. ABB does not assume any liability whatsoever for any installation which breaches the local laws and/or other regulations. Furthermore, if the recommendations given by ABB are not followed, the drive may experience problems that the warranty does not cover.

North America

Installations must be compliant with NFPA 70 (NEC)1) and/or Canadian Electrical Code (CE) along with state and local codes for your location and application. 1) National Fire Protection Association 70 (National Electric Code).

Explanation of measurements:
Rfr:
Ground fault resistances between 0 and 29.8 k can be determined and displayed. A display of 29.9 k or 30 k indicates a ground fault resistance >29.8 k. A value of 29.9 k
or 30 k is displayed when there is no ground fault.
A whole number between 100 and 111 is displayed for the
fault code in cases when it is not possible to compute the
ground fault resistance.
100.0 means no injection for more than 5 s.
101.0 means incorrect frequency. Either the injection frequency on the REX 010 or the rated frequency on the
RE. 216 is incorrectly set.
102.0 means external open-circuit.
109.0 means that both the binary inputs ‘AdjREsInp’ and
‘AdjCoupCInp’ are enabled.
111.0 means that the binary input ‘AdjRErInp’ is enabled.
No other codes will normally be generated, but if they are,
they are a diagnostic aid for the specialist

The prices of all products of Zhangzhou Fengyun may fluctuate at any time. The specific price is subject to the customer service quotation. Please confirm the model, product, price and other details with the customer service before placing the order. Second-hand and brand-new products are sold in the store. Please contact the customer service for details.

Recommended ABB related models：
